Rev 2; 7/05

MAXQ2000 Evaluation Kit

General Description

The MAXQ2000 evaluation kit (EV kit) is a proven plat-

form to conveniently evaluate the capabilities of the

MAXQ2000 low-power LCD microcontroller. The kit con-

tains the MAXQ2000 with pins brought out to headers, a

JTAG programming interface, fixed and adjustable

power supplies, a DB-9 serial connector, an LCD dis-

play, and switches and LEDs to control and display

board operation. With the included software, serial-to-

JTAG interface board, and an RS-232 cable connected

to a personal computer, the kit provides a completely

functional system ideal for evaluating the capabilities of

the MAXQ2000.

Evaluation Kit Contents

? MAXQ2000 Evaluation Kit Board with Processor

and 13.5MHz Crystal Installed

? Serial-to-JTAG Interface Board and JTAG Cable

? MAXQ2000 LCD Display Daughterboard

? MAXQ2000 Evaluation Kit CD-ROM

Ordering Information

Features

? Easily Loads Code Using Bootstrap Loader and

Serial-to-JTAG Interface Board

? JTAG Interface Provides In-Application

Debugging Features

Step-by-Step Execution Tracing

Breakpointing by Code Address, Data Memory

Address, or Register Access

Data Memory View and Edit

? Removable, Static, 4-1/2 Digit LCD Display

? DB-9 RS-232 Serial Connector and Level

Translator

? On-Board 3.6V, 2.5V and Adjustable 1.8V to 3.6V

Power-Supply Regulators

? Evaluation Kit Board can be Powered Directly

over JTAG Interface

? Processor Clock can be run from Crystal or

Programmable Oscillator

? Serial EEPROM

? DS2433 1-Wire ? EEPROM Demonstrates Use of

1-Wire Interface

PART

MAXQ2000-KIT

DESCRIPTION

MAXQ2000 EV Kit Board

? MAX1407 ADC/DAC Demonstrates Use of SPI?

Interface

? Optional LED Display of Port 0 Logic Levels

? Pushbutton Switches for Reset and Interrupt

Generation

? 32kHz Crystal for Real-Time Clock Oscillator Use

? Prototyping Area Including V DDIO and V DD Voltage

Rails

? Test/Expansion Header Includes All Device GPIO

MAXQ is a registered trademark of Maxim Integrated Products, Inc.

1-Wire is a registered trademark of Dallas Semiconductor Corp.

SPI is a trademark of Motorola, Inc.

and LCD Pins

? Configuration DIP Switches Connect/Disconnect

All Demonstration Circuitry from Port Pins

? Board Schematics Provide a Convenient

Reference Design

______________________________________________ Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,

or visit Maxim’s website at www.maxim-ic.com.
